12 - 1/2" New Scotchman (NON-FERROUS, CNC) Circular Cold Saw, (For Cutting Aluminum, Brass, Copper, Plastics), Mdl. CPO 315 RFA/NF, 5 H.P. Variable RPM Speed Control (Ferrous Model), 3.8 H.P. - 3,000 RPM (Non-ferrous Model), Automatic Tube Ejection, Clamping Both Sides of Blade - Highest Quality, Burr-Free Cuts, Interlocking Safety Hood, Blade Guides for Accurate Tolerances (Ferrous, (Scotchman) Warranty: Three Years On Parts, #SMCPO315RFASTNF

Stock No:
#SMCPO315RFASTNF
Manufacturer:
Scotchman
Model:
CPO 315 RFA/NF
Capacity:
12 - 1/2"
Condition:
New
Print a Quick Quote!
View Gallery
DETAILED SPECIFICATION
Material Type:
Non Ferrous Metals
Maximum Saw Blade
12 - 1/2"
Minimum Cut Length
1 - 1/4"
Maximum Cut Length
60"
Feed Type:
Fully Automatic
Cutting Speeds
3,000 RPM
Round Tube
3 - 1/2"
Round Solid
2"
Square Tube
3 - 1/8" x 3 - 1/8"
Square Solid
2" x 2"
Length Tolerance
+ Or - 0.004 Repeatability
Minimum Trim Cut
1"
Air Pressure
90 LBS. Minimum
Sqareness Tolerances
0.002 Per Diameter Inch
Arbor Bore Size
40 MM
Pin Spacing
4/12/64
Supply Table Width
24"
Motor HP - Non Ferrous Model
3.8 HP
Motor HP Ferrous Models
5 HP
Power Supply
208/230/460 3-PH
WEIGHT
3250 Lbs.
EQUIPPED WITH
Automatic Tube Ejection
Clamping Both Sides Of Blade - Highest Quality, Burr-Free Cuts
5 H.P. Variable RPM Speed Control (Ferrous Model)
(Scotchman) Warranty: Three Years On Parts
3.8 H.P. - 3,000 RPM (Non-ferrous Model)
Interlocking Safety Hood
Blade Guides For Accurate Tolerances (Ferrous

Additional Information

NOTE:  This is a NON-FERROUS Saw will Cut Aluminum, Brass, Copper, Plastics, without Changing the Blade.

This Saw is a 3,000 RPM Cutting Saw.  It is for Cutting Aluminum, Brass, Copper or other Soft materials ONLY.

Scotchman Is MADE IN AMERICA and comes with a 3 YEAR WARRANTY!

FULLY-AUTOMATIC Cold Saw. Automatic feed and cutting. Ideal for hi-volume jobs, magazine feed, or full bundle loader.

Larger Feeds Available.  Please Call for More information 626-444-0311



* Temporary specifications subject to verification.

  All quotations subject to prior sale.

  New pricing is good only at time of invoice and must be paid Immediately to guarantee no price increases by the manufacturers.
