14" x 40" baileigh PL-1440E, New #SMPL1440E
Machine Type:
LATHES
Manufacturer:
Baileigh
Model:
PL-1440E
Capacity:
14" x 40"
Condition:
New
Stock No:
#SMPL1440E
Starting At: $14,999.00
DETAILED SPECIFICATION
| Capacity | |
| Maximum Swing Over Bed | 14" |
| Maximum Swing Over Cross Slide | 8.6" |
| Maximum Swing Over Gap Diameter | 19.9" |
| Center Length | 40" |
| Width Of Bed | 7.086" |
| Weight (Lbs.) | 1,450 |
| Spindle Nose | D1 - 4" |
| Spindle Bore | 1.50" |
| Spindle Bore Taper | Morse #5 |
| Spindle Speeds | 8 |
| Top Slide Travel | 2.68" |
| Maximum Tool Selection | 0.625" x 0.625" |
| Cross Slide Travel | 6.29" |
| Leadscrew Thread Pitch | 8 TPI |
| Longitudinal Feed Range | 0.002" - 0.0548"/rev |
| Cross Feed Range | 0.007" - 0.0187"/rev |
| Metric Thread Range | 0.4 - 7MM |
| Inch Thread Range | 0.0157" - 0.275" |
| Sleeve Diameter | 1.65" |
| Sleeve Travel | 4.5" |
| Sleeve Taper | Morse #3 |
| Horsepower | 2 H.P. |
| Power Requirement | 220v 1-Phase |
| Dimension (L x W x H) | 79x44x63 |
| WEIGHT | 1430 lbs |
Features
Face Plate
2 Axis Digital Readout
Foot Brake
Fully Assembled
Steady Rest
Halogen Work Light
Live Center
Quick CHange Tool Holder
Coolant System With Splash Guard
#6 morse Taper
Micrometer Saddle Stop
Follow Rest
Removable Chip Tray
220V / 1-Phase
OPTIONAL EQUIPMENT AND TOOLING
Name: Import - 8" 3-Jaw (D1-4) Camlock Lathe Chuck
Price: Call For Price
Stock No:# SM3900-4607
ADD TO MACHINE QUOTE:
Additional Information
The PL-1440E metal lathe raises the bar for entry-level lathes. Built with ground and hardened slideways and a DRO, this gap lathe is reliable and precise.
- Recommended for small to medium shops and schools.
- 8 spindle speeds, ranging from 90 to 1,800 rpm.
- 3 hp motor runs on a 220-volt single-phase power, so you can use it almost anywhere.
- No assembly required. Just open the crate and wire it up.
- Precision-ground and hardened ways ensure years of tight tolerances.
- Digital readout (pre-installed) helps you make precise cuts.
- Capable of making metric and standard threads.
- Gap lathe design allows you remove a section of the slide to fit a slightly larger diameter.
- Comes standard with:
- 3-jaw and 4-jaw chucks.
- Headstock chuck guard with automatic safety switch.
- Steady rest and follow rest.
- Face plate.
- Safety foot brake.
- Integrated coolant system, which maintains accuracy and helps the machine last longer.
- Halogen work light.
- Optional taper attachment for making cones is sold separately.
- Covered by a 1-year parts warranty.
- We stock replacement parts at our Wisconsin headquarters so we can ship them out quickly.
- Our team of experienced metalworkers is here to provide lifetime technical support by phone.
* Temporary specifications subject to verification.
All quotations subject to prior sale.
New pricing is good only at time of invoice and must be paid Immediately to guarantee no price increases by the manufacturers.
