14 " x 13" Brand New Knuth Fully Automatic Horizontal Band Saw, Mdl. ABS 330 L, 3 meter roller table for ABS 330 L, Hydraulic blade tentioning for ABS 330 L, Chip conveyor for ABS 330 L, Micro spray cooling system for Band Saws 280-380, Laser pointer, Clamping Both Sides Ff Blade - Highest Quality, Burr-Free Cut, Clamping force controlled at operator panel, #SMABS330L

Knuth
Stock No:
#SMABS330L
Manufacturer:
Knuth
Model:
ABS 330 L
Capacity:
14" x 13"
Condition:
New
Print a Quick Quote!
View Gallery
DETAILED SPECIFICATION
Cutting Capacity 0° (flat) (length X Width)
14 In X 13 In
Cutting capacity 0° (round)
13 in
Cutting capacity 0° (square)
13 in
Cutting Speed Infinitely Variable
65 Fpm - 327 Fpm
Stop Length
20 In
Accuracy Of The Feeding
0.02 In
Motor Rating Main Drive
4 hp
Motor rating hydraulic pump
0.7 Hp
Motor Rating Feed
0.3 HP
Overall Dimensions (L x W x H)
109 In X 36 In X 67 In
WEIGHT
3080 Lbs
Blade Dimensions
163.78 In X 1.34 In X 0.04 In
EQUIPPED WITH
3 meter roller table for ABS 330 L
Hydraulic blade tentioning for ABS 330 L
Chip conveyor for ABS 330 L
Micro spray cooling system for Band Saws 280-380
Laser pointer
Clamping Both Sides Ff Blade - Highest Quality, Burr-Free Cut
Operator Manual
Clamping force controlled at operator panel
OPTIONAL EQUIPMENT AND TOOLING
knuth - bi-metalic bandsaw blade (3/4 t/
Name: Knuth - Bi-Metalic Bandsaw Blade (3/4 T/")
Price: Call For Price
Stock No:# KNUTH33
ADD TO MACHINE QUOTE:

knuth - bi-metalic bandsaw blade (4/6 t/
Name: Knuth - Bi-Metalic Bandsaw Blade (4/6 T/")
Price: Call For Price
Stock No:# KNUTH34
ADD TO MACHINE QUOTE:

knuth - bi-metalic bandsaw blade (5/8 t/
Name: Knuth - Bi-Metalic Bandsaw Blade (5/8 T/")
Price: Call For Price
Stock No:# KNUTH35
ADD TO MACHINE QUOTE:

* Temporary specifications subject to verification.

  All quotations subject to prior sale.

  New pricing is good only at time of invoice and must be paid Immediately to guarantee no price increases by the manufacturers.
