35.4” x 17.7” Brand New Atrump CNC Machining Center , Mdl. EL22, Centroid’s Easy Conversational Programing OAK PRO License, Huge 15” Color Touch Screen, 60GB Reliable SSD, RS232 And 2USB Ports For Easy Data X-fer., C3 Class Ball Screw is pre-loaded to reduce the effects of heat deformation. Meehanite castings, Roller Type linear Guide Way on the XYZ axes. 100% Laser tested and calibrated positioning accuracy and repeatability. High speed Delta AC motors and Drive, #SMEL22
Stock No:
#SMEL22
Manufacturer:
Atrump
Model:
EL22
Capacity:
35.4” x 17.7”
Condition:
New
DETAILED SPECIFICATION
Table
35.4” X 17.7”
X Travel
27.5"
Y Travel
17.7"
Z Travel
20.4"
Spindle Nose To Tabletop
4.3" To 25.9"
Table Load Capacity
1,320
T-Slot (5)
0.7" x 3.14"
Spindle Taper
CAT40/BT40
Programable Spindle Speed
8,000rpm
TRANSMISSION SPINDLE-MOTOR
Belt / Direct drive (OPT)
Rapid Feed Rate X/Y/Z
Belt / Direct Drive (OPT
Cutting Feed Rate
1 to 393 IPM
SPINDLE MOTOR/MAX POWER
10hp
Servo Motors on XYZ
1.8 kW / 1.8 kW / 3 kW
Tool Magazine Capacity
Armless 20 Tools
MAX. TOOL DIA
Ø 3.1"
Adj. Pocket Empty
Ø 3.54
Max. Tool Length
11.8”
Max. Tool Weight
15.4lbs Total:176lbs
Lubrication Pump
Auto Lubricatio
Floor Plan
98" X 87" X 103"
Net Weight
9,460 Lbs.
Power Requirement
12 KVA 3 Phase 208V-230V
Air Requirement
70-100 psi (5~8 kg/cm^2)
Oil Way Recommended
Mobil Vectra #2
Shell Tellus 32 Atrump Proven High Quality Machines And Promoting Centroid Control Since 198
Shell Tellus 32
EQUIPPED WITH
Centroid’s Easy Conversational Programing OAK PRO License
Huge 15” Color Touch Screen
60GB Reliable SSD
RS232 And 2USB Ports For Easy Data X-fer.
C3 Class Ball Screw is pre-loaded to reduce the effects of heat deformation. Meehanite castings, Roller Type linear Guide Way on the XYZ axes. 100% Laser tested and calibrated positioning accuracy and repeatability. High speed Delta AC motors and Drive
* Temporary specifications subject to verification.
All quotations subject to prior sale.
New pricing is good only at time of invoice and must be paid Immediately to guarantee no price increases by the manufacturers.
